TRAILER MOUNTED LIFT

LIFT, BOOM TRAILER 34'

Where to find LIFT, BOOM TRAILER 34 in Mycity
Where to find LIFT, BOOM TRAILER 34 in Mycity
Where to find LIFT, BOOM TRAILER 34 in Mycity

Image for reference only
Actual item may look different
Click on image for larger view

  • Where to find BOND 6 FT. BAR in Mycity
  • Where to find BOND 6 FT. BAR in Mycity
  • Where to find BOND 6 FT. BAR in Mycity

Click on above thumbnails for alternate view

Product Information

  • Total Weight - 3,200 lbs. / Tongue weight - ANSI, CSA 315 lbs, / CE 163 lbs
  • Working height* 40 ft, Platform height 34 ft
  • Horizontal reach 18 ft 4 in / Clear out reach 13 ft 5 in
  • Up and over clearance 16 ft 1 in
  • Platform - length 2 ft 2.8 in, width 3 ft 8 in
  • Stowed - Height 6 ft 4.5 in, Length - 18 ft .5 in, Width - 4 ft 9.1 in
  • Ground clearance 9.5 in
  • Outrigger footprint Length 10 ft 8.4 in, Width 11 ft 9.4 in
  • Lift capacity (ANSI, CSA) - rotating platform 460 lbs
  • Self leveling platform standard
  • Platform rotation option 90 mechanical
  • AC power to platform standard /
  • Turntable rotation 359 non-continuous
  • Outrigger leveling capability 10.5 (18% grade)
  • Towing speed rate 60 mph
  • Surge and parking brakes
  • Controls variable speed system
  • Tire size ST 205/75 R15
  • Coupler 2 in (5.08 cm) hitch coupler standard
  • Power source 24 V DC (four 6 V 225 Ah batteries)
Manufacturer:GENIE
Model:TZ34/20
Daily:$260.00
Weekly:$1,040.00
Monthly:$2,080.00
